PCB printed circuit board manufacturing

Availability: In stock

$0.00

Quick Overview

Special PCB price:


5 pcs 50x50 mm Double sided prototype PCB+free shipping, total: $24


5 pcs 100x100 mm Double sided prototype PCB+free shipping, total: $29


5 pcs 50x50 mm 4 layers prototype PCB+free shipping, total: $39


5 pcs 100x100 mm 4 layers prototype PCB+free shipping, total: $59


1pc 300x400mm laser cut stencil+free shipping, total: $39





For special PCB order, please send us your PCB file or gerber file via email(E-Mail: tedchen163@yahoo.com).

PCB printed circuit board manufacturing

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

* Required Fields

$0.00

Details

  • We accept gerber file or PCB source file in Altium/PADS/Protel/Eagle format for PCB manufacturing.
  • Material: FR4
  • Panel-Type:

Single piece:  1x1

Multi piece:   1 panel = x pcs

Multi drawings:   1 panel = x different drawings

  • Lead time:

Standard order: 3-4 work days for 1 or 2 layer boards, 4-5 work days for 4 layer boards

Urgent order #1: 48 hours--1 or 2 layer; 72 hours--4 layer

Urgent order #2: 24 hours--1 or 2 layer, 48 hours--4 layer

  • Silkscreen: default color is white ;  if solder mask is white, the silkscreen will be black.
  • Outer finished copper: default 1.0 oz(35um)
  • Stack up of four layer board

We will process the board by using default stack up, no blind/buried vias, if your design is different from it, please let us know the stack up of your design.

Default stack up of 4 layer PCB:
1) Top
2) GND
3) Power
4) Bottom

  • Currency:    USD
  • Attention: All prices excluding Customs and VAT
  • Shipping Costs: default is "charged by shipper", we also accept "charged by receiver " if you have valid FedEx account number.
  • Estimated delivery time of Registered Post Air-mail is 2-3 weeks while FedEx/DHL is 3-5 days.
  • For example: PCB information

REFERENCE



Quantity

5 units

Copper Layers

2

PCB Board Size

100mm x 100mm

Thickness

1.6mm

Silkscreen

White

Surface Finish

HAL PBSN

Solder Mask

Green

PCB Material

FR4

Finished Copper

1 OZ

Test

Flying Proble E-test

Panel-Type

Single piece

Lead time

3-4 work days

Price

$19



The shipping cost:

Destination country

 USA

Shipping method

Post Air-mail(ePacket)

 FedEx/DHL

Shipping cost

$10

$21

Estimated delivery time

7-10 days

3-5 days

Total

US $29

US $40

We accept payment by Paypal, our Paypal account is: diygsm@gmail.com , please inform me after payment.

  •  Welcome to place combining purchases order of PCB manufacturing with electronic components to save shipping cost
  • If you have any concerns or questions, please contact Ted Chen(E-mail: tedchen163@yahoo.com)freely.

Contact name: Ted Chen

E-mail: tedchen163@yahoo.com

Skype: DIYGSM

http://www.DIYGSM.com PCB Manufacturing
